Model Details

  • Model

    T5 Electric Truck

  • GVM (kg)

    4,500 or 6,000

  • GCM (kg)

    GVM at 4,500 + 3,500

  • Towing (kg)

    3,500 (braked); 750 (non-braked)

  • Kerb weight (kg)


  • Length/Width/Height (mm)


  • Wheel Base (mm)


  • Max speed (km/h)



  • Battery

    60Ah, 2 sets


  • Motor

    Rated/Peak power 64/115 kW

  • Cooling system

    Electric fan

    Auxiliary water tank

  • Maximum gradient


  • Frame Structure

    Vertical beam section height 180mm

  • Front axle

    Type: Forged I-beam / Payload 2.4T

  • Rear axle

    Integral type (stamped axle housing)

    Rear payload 4.5T

  • Brake

    Type: Hydraulic auxiliary brake


  • Suspension

    Front: 3 leaf springs/stabilizer bar

    Back: 5+2/stabilizer bar

  • Steering

    Electric steering

    Multifunction steering wheel with bluetooth

  • Tyres

    205/75 R16LT / + spare tyre

    Rim material: Alloy

  • Cabin

    Power windows and doors

    Windshield: Colourless laminated glass

    Rear window glass: Colourless area tempered

    Door lock: Central control/electric door lock

  • Audio

    MP5(MP5+Radio+MP3+USB+AUX+Reversing Image)

  • Airconditioning

    Integrated heating and cooling

    Control: electric

  • Safety

    Driver and front passenger air bags

    Unclosed door warning

    Warning of unlocked front cab

    Key alarm device

    VSP (Low Speed Pedestrian Warning System)

    Rear lower guard/Side guard

    Reversing radar & buzzing

    Reverse image

    Reversing buzzing

  • Charging

    Fast Charge: ~1.5 hours

    Slow Charge: ~7.5 hours

Vehicle Warranty

Vehicle Warranty

5 years or 200,000km

Electric Motor Warranty

Electric Motor Warranty

5 years or 200,000km

Power Battery Warranty

Power Battery Warranty

8 years or 300,000km
